| HS Code | 407268 |
| Product Name | Electrolyte for Layered Oxide/Hard Carbon Battery |
| Electrolyte Salt | NaPF6 |
| Salt Concentration | 1.0 M |
| Solvent System | EC:DMC:EMC (1:1:1 wt%) |
| Additive | 5% FEC |
| Ionic Conductivity | 6.5 mS/cm at 25°C |
| Operating Temperature Range | -20°C to 60°C |
| Electrochemical Stability Window | 0.0 V to 4.5 V vs Na/Na+ |
| Water Content | <20 ppm |
| Density | 1.20 g/cm3 at 25°C |
| Viscosity | 4.2 mPa·s at 25°C |
| Flash Point | 135°C |
| Appearance | Colorless transparent liquid |
As an accredited Electrolyte for Layered Oxide/Hard Carbon Battery factory, we enforce strict quality protocols—every batch undergoes rigorous testing to ensure consistent efficacy and safety standards.
| Packing | Packaged in 100 mL sealed glass bottle with PTFE-lined cap, stored under inert argon, labeled with handling precautions. |
| Container Loading (20′ FCL) | 20′ FCL: Electrolyte in UN-approved drums/pails, dangerous goods, secure bracing, ventilation, spill containment, and segregation per IMDG. |
| Shipping | Ship as hazardous material (Class 3 flammable liquid) in sealed, corrosion-resistant containers. Label with proper UN number and lithium-battery electrolyte markings. Use dry, ventilated packaging; avoid moisture, heat, and direct sunlight. Comply with IATA/IMDG/ADR regulations. Ground freight recommended; air shipment requires approved packaging and documentation. |
| Storage | Store in tightly sealed, corrosion-resistant containers under a dry, inert atmosphere (argon or nitrogen) in a cool, well-ventilated area. Keep away from heat, sparks, open flames, and incompatible materials. Avoid prolonged exposure to air or moisture, as the electrolyte can degrade, generating hazardous byproducts. Label clearly and follow all safety data sheets. |
| Shelf Life | Typically 12 months when stored sealed, cool, and dry; protect from moisture, air, and direct sunlight to maintain performance. |
High-capacity prismatic cells built with O3-type layered oxide cathodes and hard carbon anodes are filled with 1.0 M NaPF6 electrolyte in 1:1:1 EC:EMC:DEC by volume, with fluoroethylene carbonate held at 2.0 wt% of total electrolyte mass. For a 280 Ah class cell, the electrolyte addition ratio is specified at 3.2–3.8 g Ah⁻¹ after vacuum bake at 85 °C for 12 h; pre-fill cell moisture is controlled to ≤250 ppm, and the filling operation is conducted in a dry room with dew point ≤ -40 °C. The electrolyte is injected at 20–25 °C under -0.08 MPa to prevent solvent flashing. Fill tolerance is held at ±0.2 g Ah⁻¹ because underfilling leaves unwetted electrode edges and overfilling increases can deformation and electrolyte leakage risk during formation. Compliance for containerized commercial and industrial storage systems is anchored to IEC 62619:2022, UN 38.3, UL 9540A, RoHS Directive 2011/65/EU, and REACH Regulation (EC) No 1907/2006 Candidate List screening for electrolyte constituents.
| Compliance anchor | Test method / designation | Application scope |
|---|---|---|
| IEC 62619:2022 | overcharge, forced discharge, external short circuit | industrial sodium-ion cells and modules for C&I storage |
| UN 38.3 | T1 altitude simulation through T8 forced discharge | transport safety for finished cells and packs |
| UL 9540A | cell-to-cell thermal runaway propagation | energy storage system installation approval |
| RoHS 2011/65/EU | restricted substances screening | EU market access for cell, module, and electrolyte |
Downstream production uses slot-die coating for the hard carbon anode slurry, with carboxymethyl cellulose/styrene-butadiene rubber binder coated on aluminum foil, while the O3-type layered oxide cathode is coated with NMP-based PVDF slurry on aluminum foil. The anode current collector remains aluminum because sodium does not alloy with aluminum at hard carbon potentials. Cells are wound or stacked, tab-welded by ultrasonic or laser methods, filled, and then formed at 0.05C initial wetting charge and 0.1C to 4.0 V, followed by degassing, final seal, and 45 °C aging for 7 days. Terminal products include 100 kW/200 kWh commercial cabinets, 1 MWh containerized arrays, and peak-shaving systems co-located with photovoltaic generation. The electrolyte must not be exposed to ambient air after opening because NaPF6 hydrolyzes to HF at moisture levels above 200 ppm; cells stored above 45 °C show accelerated calendar fade, and cells should not be cycled below 2.0 V per cell because deep discharge destabilizes the hard carbon SEI and increases impedance during the next charge.
In 48 V telecom outdoor cabinets, layered oxide/hard carbon cylindrical cells are filled with 1.0 M NaPF6 in EC:PC:DEC at 1:1:1 volume ratio; the inclusion of propylene carbonate is permissible because hard carbon does not undergo the solvent co-intercalation exfoliation observed with graphite anodes. For 26700 cylindrical cells, electrolyte retention after centripetal vacuum filling is 4.0–4.6 g Ah⁻¹, and fluoroethylene carbonate is maintained at 2.0 wt% to stabilize the hard carbon SEI during long-duration float and deep-cycle duty. The downstream process winds the electrode pair around a central mandrel, inserts the jelly roll into a nickel-plated steel or aluminum can, laser-welds the cap, and fills under vacuum at 20–25 °C. Formation is performed at 0.1C to 4.0 V, followed by 45 °C aging and open-circuit voltage sorting over 14 days.
Compliance for the assembled 16S1P 48 V string is evaluated under IEC 62619:2022, UN 38.3, and ETSI EN 300 019-1-4 for weather-protected non-climate-controlled telecom locations. Terminal products include 48 V 100 Ah outdoor modules, 19-inch rack-mounted backup batteries, and remote tower sites where deep-cycle resilience is required through repeated grid interruptions. At temperatures below -10 °C, charge current is derated to 0.1C unless cell heating is active, and float voltage should not exceed 4.0 V per cell to avoid electrolyte oxidation at the layered oxide cathode. Storage or transport at full charge above 35 °C is not recommended because NaPF6 hydrolysis by residual moisture accelerates pressure increase inside the cylindrical can.
Layered oxide/hard carbon pouch cells for electric two-wheelers and A00-class micro EVs are filled with 1.0 M NaPF6 in EC:DEC at 1:1 volume ratio, with fluoroethylene carbonate at 1.5–3.0 wt% of total electrolyte mass. The electrolyte addition ratio is 2.8–3.3 g Ah⁻¹ in 15–25 Ah cells because thinner electrode stacks reduce void volume relative to high-capacity prismatic cells. The downstream process disperses the layered oxide cathode powder in NMP with PVDF binder for coating on 15 μm aluminum foil, and coats hard carbon with CMC/SBR binder on 12 μm aluminum foil. After slitting and stacking with a polyolefin separator, aluminum laminate film is deep-drawn, tabs are ultrasonically welded, and electrolyte is injected in a dry room at dew point ≤ -40 °C. Formation is performed at 0.1C to 4.0 V, followed by hot pressing at 60 °C, vacuum degassing, and second seal.
Compliance for the battery pack includes IEC 62619:2022, UL 2271, UN 38.3, and RoHS Directive 2011/65/EU. Terminal products are 36 V and 48 V e-bike batteries, 72 V scooter packs, and 4–8 kWh micro-EV battery systems. At -20 °C, the EC-rich electrolyte increases ionic resistance, and charging must be limited to 0.1C or prevented below -20 °C unless the pack is equipped with active warm-up. Discharge to 1.5 V per cell is permitted only under low-rate conditions; hard carbon impedance rises sharply below 2.0 V, and repeated deep discharge increases irreversible sodium loss at the anode.
For residential wall-mount and high-voltage stackable systems, the electrolyte is selected for low gas generation over a design target of 6,000 cycles at 80% depth of discharge. A 100 Ah prismatic cell using layered oxide/hard carbon chemistry is filled at 3.0–3.5 g Ah⁻¹ with 1.0 M NaPF6 in EC:DEC 1:1, plus fluoroethylene carbonate at 2.0 wt%. No ester co-solvent is added because the residential duty cycle prioritizes calendar life over low-temperature rate capability. The downstream process laser-welds an aluminum top cover, performs helium leak detection to 1×10⁻⁸ Pa·m³/s, injects electrolyte after 85 °C vacuum drying, and then forms the cell at 0.05C to 3.0 V wetting step and 0.1C to 4.0 V, followed by 14-day room-temperature aging and capacity grading.
Compliance is reviewed under IEC 62619:2022, UL 1973, UN 38.3, and IEC 62477-1:2022 for power converter integration. Terminal products include 5 kWh wall-mount modules at 48 V, 10–20 kWh high-voltage stacks composed of series-connected modules, and hybrid inverter-coupled storage for rooftop photovoltaic self-consumption. The operating boundary for cells in these stacks is 0 °C to 45 °C. Above 40 °C, charge current is derated to 0.3C, and storage at 100% state of charge above 35 °C accelerates NaPF6 hydrolysis and increases gas pressure in the can. Low-temperature operation below -10 °C requires reduced charge current and BMS-controlled cold-start preheating.
High-rate partial-state-of-charge cycling in automated guided vehicles and electric forklifts imposes an electrolyte formulation that balances ionic conductivity against hard carbon anode passivation. For 20 Ah pouch cells with layered oxide/hard carbon chemistry, the filling ratio is 2.5–3.0 g Ah⁻¹, and the solvent system uses EC:DMC at 1:2 by volume to lower viscosity. NaPF6 concentration is 1.0 M, and fluoroethylene carbonate is increased to 2.5 wt% because aggressive charge acceptance during opportunity charging accelerates SEI damage. The downstream process is configured for high-rate tab and cell design: hard carbon electrodes are double-side coated and slit with multiple current collector tabs, and the aluminum-laminate pouch is vacuum-filled and formed at 0.1C before a partial-state-of-charge screening at 3C charge and 5C discharge for 50 cycles.
Compliance is tied to EN 1175:2020, IEC 62619:2022, and UN 38.3. Terminal products include 24 V and 48 V AGV battery packs, 80 V forklift replacements for lead-acid units, and pallet-truck power systems operating in cold-storage warehouses at -20 °C. The pack state-of-charge window is restricted to 20–90% for high-rate duty. Continuous discharge above 5C is not recommended because cell internal temperature may exceed 55 °C, triggering accelerated NaF dissolution from the hard carbon SEI. Published field data for this specific configuration remains limited beyond 2,000 high-rate cycles, so end-of-life validation must be appraised on a cell-lot basis.
Competitive Electrolyte for Layered Oxide/Hard Carbon Battery prices that fit your budget—flexible terms and customized quotes for every order.
For samples, pricing, or more information, please contact us at +8615365186327 or mail to admin@ascent-chem.com.
We will respond to you as soon as possible.
Tel: +8615365186327
Email: admin@ascent-chem.com
Flexible payment, competitive price, premium service - Inquire now!
EL-LO/HC-042 is a non-aqueous carbonate electrolyte formulated specifically for sodium-ion rechargeable cells that pair layered transition-metal oxide cathodes with hard carbon anodes. The base solvent system is a binary carbonate blend of ethylene carbonate and diethyl carbonate at a mass ratio of 40:60, with sodium hexafluorophosphate controlled at 1.0 mol L−1. Fluoroethylene carbonate is present at 2.0 wt% and sodium bis(oxalato)borate at 0.5 wt% to regulate hard carbon solid-electrolyte interphase formation. The product is intended for cells with a nominal voltage of 3.0 V and a maximum charge voltage of 3.95 V against Na/Na+. In three-electrode pouch-cell qualification trials, the formulation maintained an anodic leak current below 10 µA cm−2 at 3.95 V on a stainless steel working electrode, with linear sweep voltammetry conducted at 1.0 mV s−1. The product is supplied in 200 L stainless steel drums under nitrogen blanket, with moisture content at release below 15 mg kg−1 by Karl Fischer coulometric titration according to ASTM E1064.
Use of this electrolyte is limited to sodium-ion chemistry. It is not compatible with lithium-ion graphite anodes because the larger sodium ion and the differing carbonate-solvation shell produce graphite intercalation compounds of low electrochemical stability. If used in lithium-ion test cells, the electrolyte would fail to meet lithium-ion conductivity and oxidation-stability expectations. It is also not formulated for sodium metal anodes, where soluble polysulfide or ionic-liquid systems may be required to prevent dendritic penetration.
The release limits are defined for bulk electrolyte at 25 °C and 40 % relative humidity, with sampling performed under inert gas. The values in Table 1 are batch-release specifications, not in-use limits after opening.
| Parameter | Release Limit | Method or Equipment |
|---|---|---|
| NaPF6 concentration | 0.98–1.02 mol L−1 | Ion chromatography with conductivity detection |
| Water content | ≤ 15 mg kg−1 | ASTM E1064, coulometric Karl Fischer |
| Free acid as HF | ≤ 50 mg kg−1 | Acid-base titration after hydrolysis, internal method based on IEC 62314 |
| Density at 25 °C | 1.18–1.24 g cm−3 | ASTM D4052, oscillating U-tube densitometer |
| Dynamic viscosity at 25 °C | 4.2–5.8 mPa·s | ASTM D7042, rotational viscometer |
| Ionic conductivity at 25 °C | 6.2–7.8 mS cm−1 | Impedance cell with cell constant 0.1 cm−1 |
| Chloride | ≤ 3 mg kg−1 | Inductively coupled plasma mass spectrometry |
| Electrochemical stability window | 2.8–3.95 V vs Na/Na+ | Linear sweep voltammetry on stainless steel at 1.0 mV s−1 |
The moisture limit of 15 mg kg−1 is a release control, not a storage target. Once a drum is opened, moisture ingress must be monitored by in-line Karl Fischer sampling at the day tank. Field observations from pouch-cell dry rooms indicate that headspace nitrogen with more than 20 mg kg−1 water can increase free acid content within 48 h. Hydrolysis of NaPF6 produces HF and POF3, and free acid can rise above the 50 mg kg−1 release threshold. Elevated free acid increases transition-metal dissolution from layered oxide cathodes and accelerates hard carbon SEI thickening. In electrolyte qualification programs, free acid is therefore measured again after 72 h of storage at 45 °C in sealed stainless steel sampling vessels.
Vacuum filling of layered oxide/hard carbon pouch cells is controlled by the viscosity and wetting behavior of the electrolyte. At 25 °C, the dynamic viscosity remains between 4.2 mPa·s and 5.8 mPa·s, which supports wetting of dry electrodes with combined anode and cathode porosity of 28% to 35%. On a high-speed pouch-cell vacuum filling line with segmented chambers at −95 kPa gauge, wetting of a 5.0 mAh cm−2 hard carbon anode is completed within 90 s when the electrolyte is held at 20 °C. Lower temperatures raise viscosity and extend wetting time beyond 120 s, reducing throughput in dry rooms maintained at −40 °C dew point and oxygen below 50 ppm. Electrolyte transfer from bulk storage to day tanks should use low-shear gear pumps with fluoropolymer seals; bronze impellers or brass fittings are incompatible because copper ion contamination degrades the hard carbon SEI and promotes sodium metal plating at low potential.
Venting and formation are additional production constraints. During first charge at 45 °C, gas generation in pouch cells is dominated by carbonate reduction on hard carbon and by residual moisture hydrolysis. A formation protocol using C/10 charge to 3.95 V with a 1 h constant-voltage step produces less than 2.5 mL Ah−1 of gas for cells with electrode moisture below 200 ppm. If electrode moisture exceeds 400 ppm, gas volume rises and pouch swelling forces additional degassing steps that introduce contamination risk. The additive package containing fluoroethylene carbonate and sodium bis(oxalato)borate reduces first-cycle gas generation compared with additive-free NaPF6/EC:DEC by promoting an inorganic NaF-rich SEI. Published data for this specific formulation under 60 °C floating storage is limited; qualification programs therefore rely on accelerated storage at 55 °C with intermittent electrochemical impedance spectroscopy.
Hard carbon anodes in sodium-ion cells exhibit the largest performance loss when charging at 0 °C to −10 °C. The EL-LO/HC-042 electrolyte is not formulated for full-rate charging below 0 °C. In three-electrode cell tests with a sodium reference, the hard carbon potential falls below 0 V vs Na/Na+ at −10 °C when the charge rate exceeds C/5, leading to sodium metal plating on the hard carbon surface. This is analogous to lithium plating in lithium-ion cells but is more difficult to detect because sodium metal is softer and sodium dendrite propagation in carbonate electrolytes is faster. The low-temperature charge limit is C/10 at −5 °C, and charge termination is set at 3.90 V instead of 3.95 V. At 25 °C, the charge rate can be increased to C/2 up to 3.95 V. These limits are derived from anode half-cell potential measurements rather than from accelerated cycle tests alone.
Layered oxide cathodes used with this electrolyte are typically O3-type or P2-type sodium transition-metal oxides containing nickel, iron, manganese, and titanium. The electrolyte must not promote aluminum current collector pitting. Linear polarization on aluminum in the potential range 3.0–3.95 V vs Na/Na+ shows no measurable anodic current above baseline at 60 °C. Sodium hexafluorophosphate provides passivation of the aluminum current collector through AlF3 formation. If chloride contamination exceeds 5 mg kg−1, pitting initiates at potentials above 3.8 V, causing rapid capacity loss. This is one reason the chloride release limit is set at 3 mg kg−1 in Table 1. Separator wetting in wound cylindrical cells requires a minimum electrolyte uptake of 0.8 g Ah−1, with polypropylene and polyethylene separators both showing complete wetting within 60 s at 25 °C.
Lithium-ion electrolyte specifications cannot be reused without modification for sodium-ion layered oxide/hard carbon cells. EL-LO/HC-042 has lower ionic conductivity than a typical 1.0 mol L−1 LiPF6 EC:EMC electrolyte: 6.2–7.8 mS cm−1 versus 9–11 mS cm−1 at 25 °C. The lower conductivity is partially offset by lower charge-transfer resistance on hard carbon at temperatures above 15 °C, but it becomes rate-limiting at low temperature. Electrochemical stability also differs. The sodium formulation has an oxidation onset of approximately 4.0–4.2 V vs Na/Na+ on stainless steel, while conventional lithium-ion electrolytes can tolerate up to 4.3 V vs Li/Li+. For layered oxide cathodes requiring charge above 4.0 V vs Na/Na+, this product is not recommended.
The solvent architecture also differentiates the product from generic lithium-ion carbonate blends. Sodium salts in carbonate solvents form weaker ion pairing at equivalent concentration, but the larger ionic radius of Na+ lowers overall mobility. The binary EC:DEC solvent system in EL-LO/HC-042 is selected to balance electrochemical stability with viscosity. The absence of dimethyl carbonate reduces high-temperature transesterification by-products in the sodium cell environment. Compared with an additive-free NaPF6/EC:DEC formulation, the fluorinated additive package shifts the hard carbon SEI toward NaF and organic sodium alkyl carbonate species. The resulting interface has higher interfacial stability as measured by charge-transfer resistance growth during storage at 45 °C.
The most direct product differences are shown in Table 2. Sodium perchlorate systems are historically used in sodium-ion research because of their wider apparent oxidation stability and lower cost, but sodium perchlorate is a strong oxidizer and is not preferred for production-scale pouch cells. Aqueous electrolytes for sodium-ion cells are limited by the water oxidation potential of 1.23 V and cannot support 3.0 V layered oxide/hard carbon cells without concentrated water-in-salt formulations that raise cost and viscosity.
| Property | EL-LO/HC-042 | Typical LiPF6 EC:EMC | Typical NaClO4 PC |
|---|---|---|---|
| Electrolyte type | Non-aqueous carbonate, sodium salt | Non-aqueous carbonate, lithium salt | Non-aqueous carbonate, sodium oxidizer salt |
| Conductivity at 25 °C | 6.2–7.8 mS cm−1 | 9–11 mS cm−1 | 5–6 mS cm−1 |
| Upper practical voltage | 3.95 V vs Na/Na+ | 4.30 V vs Li/Li+ | 3.90 V vs Na/Na+ |
| Primary hazard classification | Water-reactive; HF generation | Water-reactive; HF generation | Oxidizer; handled under strict contamination control |
| Compatibility with hard carbon | Formulated for SEI formation | Not suitable; sodium intercalation is weak | Moderate; SEI lacks fluorinated inorganic component |
| Recommended temperature window | 0 °C to 45 °C | −20 °C to 60 °C | 10 °C to 40 °C |
The recommended processing window for EL-LO/HC-042 is 0 °C to 45 °C. Storage below 0 °C may cause partial carbonate crystallization, especially in drums with high ethylene carbonate mass fraction. Storage above 45 °C accelerates NaPF6 hydrolysis and carbonate transesterification. The electrolyte should not be combined with amine-cured epoxy sealants in cell headers because residual amines raise apparent free acid and catalyze carbonate degradation. Transfer lines and filling nozzles should be constructed from 316L stainless steel or fluoropolymer-wetted components. The product is not recommended for cells that require charging above 4.0 V vs Na/Na+, for sodium metal anode configurations, or for direct substitution into lithium-ion cell designs without reformulation of the electrode coating and formation protocol.
